VMD80

• Advanced digital truck scale program with tons of new functions
• Improved built-in surge protection assures longer lifetime
• Complete connectivity with up to 16 digital load cells
• Self diagnostics minimizing possible risks from load cell or communication errors
• Flexible communications with RS232, RS485, Analog Out, Modbus - RTU
• Dual power supply with AC and 12V external rechargeable battery
•

• 	260(L) x 100(W) x 200(D) mm (11.8 x 5.5 x 9.5 in.), S/S enclosure
  Keypad	24 tactile keys with numeric keys, function keys, application keys
  Display	7 digits super-bright LED, 7 status indicator
  Internal Resolution	1,000,000
  Displayed Resolution	100,000
  Repeatability	±0.01% F.S.
  Excitation Voltage	15VDC
  Decimal Points	Configurable
  Warm-up Time	Self test complete
  Communications	Two serial ports (RS232/RS485 - RS232/20mA) Analog Output Modbus RTU
  Power Input Voltage Frequency	110-230VAC ±10% / 12VDC 50/60Hz ±10%
  Power Consumption	45VA max
  Scale Types	Power up to 16 x digital load cells
  Calibration	Multi-point calibration
  Update Rate	50 per second
  Operating Temperature	-10°C to +40°C
  Shipping Weight	4.5 kg (10 lbs)

• Specifications subject to change without notice.
•
